Solar Street Garden Light/Lamp Lighting System

Customization: Available
Light Source: LED Light
Color Temperature(CCT): Cool White

Product Description

Basic Specifications
Model NO.
DDXLED-09
Body Material
Aluminum
Lamp Power
60W
Power Supply
DC / 24V
Average Life
5500h
IP Rating
IP66
Application
Highway, Square, Garden
Certification
CE, RoHS, CCC, ISO, FCC, EMC, GS
Height Options
3m to 12m
Solar Panel
Mono/Poly
Production
50000 PCS/Month
Origin
China
Product Features
Advanced Manufacturing With over 14 years of production experience, we utilize professional vertical production lines to ensure superior quality control and cost-efficiency.
High Capacity Monthly production capacity of up to 20,000 galvanized street light poles ranging from 3M to 35M.
Durable Finish Hot-dip galvanizing and powder painting provide an anti-corrosion lifetime of ≥20 years.
Solar Street Garden Light System Lighting System Specification
Technical Specifications
  • Material: High-quality steel Q235/SS400
  • Welding: Automatic submerged arc welding (GB11345 Grade II)
  • Surface: Hot dip galvanizing (≥ 86um) and powder painting (≥ 100um)
  • Wind Resistance: Up to 36.9m/s
  • Pole Type: Conical, Polygonal, Round, Octagonal
Item Series Pole Height LED Lamp Solar Panel Battery Controller
Series 306m30W90W120AH10A/12V
Series 406m40W120W150AH10A/12V
Series 507m50W150W200AH10A/12V
Series 608m60W180W2*120AH10A/24V
Series 9010m90W2*140W2*180AH10A/24V
Series 12012m120W2*180W2*220AH10A/24V
Production Process
Pole Dimensions Reference
Height (m) Dimension (mm) Thickness (mm) Flange Size (mm)
660/1402.75240*240*12
760/1703280*280*12
870/1803280*280*14
970/1703.5300*300*16
1070/1703.5300*300*16
Packaging & Delivery
Professional Packaging: Bulb wrappings for FCL goods; felt wrapping followed by bulb wrappings for LCL light poles to prevent surface damage.
Lead Time: Generally 20 working days for an order of 100 galvanized steel light poles. Our integrated production includes cutting, bending, welding, polishing, and painting.
Frequently Asked Questions
What is the lifespan of the street light poles?
The poles are treated with hot-dip galvanizing and powder painting, providing an anti-corrosion lifetime of 20 years or more.
What materials are used for the lamp body and pole?
The lamp body is made of high-grade Aluminum, and the poles are constructed from high-quality Q235/SS400 steel.
Can the lighting system withstand strong winds?
Yes, our street light poles are designed with an anti-wind capacity of up to 36.9m/s.
What certifications do your products hold?
Our products are fully certified with CE, RoHS, CCC, ISO, FCC, EMC, and GS standards.
What are the typical applications for these lights?
They are ideal for various outdoor lighting projects, including highways, city squares, gardens, and residential streets.
What is the standard delivery time?
The typical production and delivery time is approximately 20 working days for a batch of 100 poles.
